Servo Voltage Stabilizers

Servo Voltage Stabilizers Specification

Output Current
30A-800A (varies by model) Volt (v)

Input Voltage
170V - 270V / 300V - 470V (single/three phase options) Volt (V)

Output Voltage
230V AC / 400V AC Volt (V)

Efficiency
> 95%

Frequency (MHz)
50 Hz / 60 Hz Hertz (HZ)

Warranty
Yes

Current
r, h, e, O, t Volt (v)

Weight
80 kg - 1500 kg (as per rating) Kilograms (kg)

Ambient Temperature
-5 C to +50 C Celsius (oC)

Phase
One phase servo

Degree of Protection
IP21 / IP42

Display Type
LED

Material
Plastic

Control System
Electric

Rated Current
50 a Ampere (amp)

Usage
Other

Insulation Resistance
>= 5 Mega Ohms at 500 V DC

Design
Compact floor-mounted, enclosed cabinet

Voltage Protection
Under/Over Voltage Protection

Display
Other

Dimension (L*W*H)
Custom as per rating (Example: 910 x 710 x 1480 mm for standard units) Meter (m)

Rated Power
Up to 500 kVA (varies by model)

Current Type
AC

Waveform Distortion
Nil - Does not distort output waveform

Product Type
Servo Voltage Stabilizers

Installation Location
Indoor/Outdoor (with customization)

Operational Altitude
Up to 2000 meters above sea level

Regulation
±1% to ±2%

Mounting Type
Floor Mounted

Transformer Type
Copper Wound/Aluminium Wound

Response Time
<10 ms

Cooling
Oil Cooled/Air Cooled options

Output Connections
Cable/Busbar as per rating

Color
Standard Siemens Grey or custom

Surge Protection
Available

Compatible Standards
IS 9815, IEC 60076

Correction Speed
35V/sec to 60V/sec

Noise Level
Below 50 dB

Environmental Compliance
RoHS Compliant

Servo Voltage Stabilizers Trade Information

Minimum Order Quantity
2 Units

Supply Ability
1000 Units Per Month

Delivery Time
7 Days

About Servo Voltage Stabilizers

Experience phenomenal power stability with our elite, new Servo Voltage Stabilizers-crafted for those demanding limited stock of unassailable performance. Equipped with rapid correction speeds (35V/sec to 60V/sec), precise regulation (1-2%), and wondrous surge protection, these units merge durability and innovation. Choose from copper or aluminium wound transformers, oil/air cooled designs, and floor-mounted, compact cabinets for seamless indoor or outdoor installations. Each model adheres to IS 9815 and IEC 60076, boasting RoHS compliance, efficiency >95%, and digital/analog displays-all enclosed in Siemens Grey (or custom) for a truly elite experience.

Application Sites & Competitive Edges of Servo Voltage Stabilizers

Servo Voltage Stabilizers are ideally suited for industrial and commercial applications demanding robust power stability. Their compact, floor-mounted design makes them perfect for manufacturing units, hospitals, commercial complexes, and data centers-both indoors and outdoors. Enjoy a competitive edge with fast correction speed, nil waveform distortion, surge protection, and stringent efficiency standards, ensuring equipment safety and operational continuity. Customizable feature sets further enhance their versatility for varied site requirements.

FOB Port, Delivery Timeline & Export Policy

Our Servo Voltage Stabilizers are exported via major Indian FOB ports. Shipped goods can be delivered in a timeframe tailored to your outlay-typically 2-4 weeks, depending on model and customization. For international clients, our export market reach is robust; sample policies are flexible, offering demonstration units at competitive rates. All goods are securely packed as per industry standards to ensure damage-free transit and timely dispatch.

FAQ's of Servo Voltage Stabilizers:

Q: How do Servo Voltage Stabilizers benefit industrial and commercial users?

A: Servo Voltage Stabilizers deliver precise voltage control, surge protection, and high efficiency, ensuring consistent electricity supply. This protects sensitive equipment from voltage fluctuations and reduces unplanned downtime.

Q: What correction speeds and voltage ranges are supported by these stabilizers?

A: These stabilizers correct voltage at phenomenal speeds of 35V/sec to 60V/sec, handling input voltages from 170V-270V (single-phase) and 300V-470V (three-phase), making them suitable for diverse operational needs.

Q: Where can these Servo Voltage Stabilizers be installed?

A: They can be installed in indoor and outdoor settings, with customization options available for environmental protection and mounting preferences, accommodating spaces like manufacturing facilities, hospitals, and commercial buildings.

Q: What is the process for getting a customized Servo Voltage Stabilizer?

A: Simply provide your operational requirements, such as power rating, cooling preference, mounting type, and site conditions. Our team will recommend or build a stabilizer tailored to your needs, ensuring compliance with applicable standards.

Q: When is surge protection especially important in these stabilizers?

A: Surge protection is especially vital in applications with sensitive equipment or environments prone to voltage spikes. It ensures safety and longevity for devices in high-risk areas such as laboratories, data centers, and medical facilities.

Q: What warranties and compliance certifications come with your Servo Voltage Stabilizers?

A: Each unit comes with a manufacturer's warranty and meets IS 9815 and IEC 60076 standards. Additionally, they are RoHS-compliant, certifying adherence to environmental and safety regulations.
